- Size: 5
- Place of Origin: China
- Brand Name: Jinan Huwai cnc machine
- Model Number: 1390
- Weight: 100.000 kg
Technical Parameters
Model | SW-1390 |
Engraving Size | 1300*900mm |
Laser Power | RECI 90W /RECI 100W |
Cutting Speed | 0 - 54,000mm/min |
Repeat Accuracy | ±0.1mm |
Power Supply | AC 220V ±10%, 50 - 60Hz |
Power Consumption | <1,000W |
Working Humidity | 8 - 95% |
Min. Engraving Size for Texts | 1 x 1mm for letters, 2 x 2mm for Chinese Characters |
Output File Format | BMP, HPGL, PLT, DST, DXP, and AI |
Driven Method | Stepper driving |
Cooling Method for Laser | Water-cooling or selected cooler |
Other Auxiliary Equipment. | Exhaust gas fan and gas pump for cooling material |
Laser Control Software | DSP Control System |
Compatible Software | CorelDraw AutoCAD Photoshop |
Laser Tube Type | CO2 Glass Laser Tube |
Main application:
Available materials: acrylic, PVC, rubber sheet, plastic, crystal, glass, wood, bamboo, oxhorn,
figuline,marble, leather, cloth, double-color board, etc. nonmetal materials
Comprehensive application: advertisement, arts and crafts, toys, textile garment, leather, car,
mechanism, electron, building upholster, timekeeper and jewelery industry and so on.
lengthen the X and Y axis, can be used for large scale material processing. Adopted international
leading parts, cost performance is high.
It uses the double motors to drive the machine and uses the double axis to transmit the machine
smoothly. So it is guaranteed not to out of shape and shake when it works for a long time.
- Size: 5
- Place of Origin: China
- Brand Name: Jinan Huwai cnc machine
- Model Number: 1390
- Weight: 100.000 kg
Technical Parameters
Model | SW-1390 |
Engraving Size | 1300*900mm |
Laser Power | RECI 90W /RECI 100W |
Cutting Speed | 0 - 54,000mm/min |
Repeat Accuracy | ±0.1mm |
Power Supply | AC 220V ±10%, 50 - 60Hz |
Power Consumption | <1,000W |
Working Humidity | 8 - 95% |
Min. Engraving Size for Texts | 1 x 1mm for letters, 2 x 2mm for Chinese Characters |
Output File Format | BMP, HPGL, PLT, DST, DXP, and AI |
Driven Method | Stepper driving |
Cooling Method for Laser | Water-cooling or selected cooler |
Other Auxiliary Equipment. | Exhaust gas fan and gas pump for cooling material |
Laser Control Software | DSP Control System |
Compatible Software | CorelDraw AutoCAD Photoshop |
Laser Tube Type | CO2 Glass Laser Tube |
