- Size: 13
- Place of Origin: China
- Brand Name: Huawei
- Model Number: 1325
- Weight: 800.000 kg
- :
- :
- :
- :
- :
- :
- :
- :
- :
- :
1. Lathe bed is welded with thicker square tube 8mm and is processed by high temperature tempering treatment.
2. Z axis adopts TBI ball-screw .
3.X Y axis adopted high precision rack gear transmission.
4.Taiwan HIWIN 20mm square guide rail, high accuracy and longer service time.
5. Adopting stepper motors and leadshine drivers.
6. Water-cooling spindle 3.2KW. and Fuling inverter3.7kw.
7.Compatible with several CAD/DAM designing software, e.g. Type 3 Artcam/Castmate/Ucancam.
8. Has the function of re-carving after break point and power failure.
9. Advanced Nc studio system or DSP control system(optional).
10.The machine can work continuously for 24 hours.
11. Free training in factory. (it takes about 3-5 days)
- Size: 13
- Place of Origin: China
- Brand Name: Huawei
- Model Number: 1325
- Weight: 800.000 kg
- :
- :
- :
- :
- :
- :
- :
- :
- :
- :
Parameters of SW-1325 cnc router machine | |
X,Y,Z working area | 1300*2500*200mm |
X,Y,Z Traveling positioning accuracy | ±0.03/300mm |
Lathe bed frame | Steel square tubes |
X,Y Structure | Rack and Pinion Drive |
Z Structure | Taiwan TBI Ball Screw |
Drive motors | leadshine step system |
Table surface | T- type table or vacuum table |
Working speed | 0-18000mm/min |
Spindle power | 3.0KW(option) water cooling spindle |
Spindle speed | 0-24000RPM/min |
Spindle inverter | fulin inverter |
Working voltage | AC380V3PH/50Hz(Option:220V/3PH/50Hz) |
Command language | G Code |
Operation system | NC studio system/DSP control system |
X,Y Resolution | <0.02mm |
Running environment temperature | 0-45°C |
Relative humidity | 30%-75% |
