- Size: 8
- Place of Origin: China
- Brand Name: Huawei
- Model Number: 1212
- Weight: 700.000 kg
- :
- :
- :
- :
- :
- :
- :
- :
- :
- :
Features:
1. The whole bed welding,after high temperature tempering, ensure the body
deformation,good rigidity, high strength.
2. using imported high precision ball screw, 20bearing steel round linear guides
3. The X,Z axis adopt dustproot structure, durable ball screw
4. Excellent mechanical and electrical design,selection of all kinds of electrical
accessories, to minimize the failure rate.
5. High cutting speed,high accuracy and low cost
A breakpoint, a power outage continued carving function,Back to the origin with
automatic correction function, effectively ensure the machine accuracy in the long working time
6. Applicable to all types of advertising:metal words, arts and crafts, logo,crytal cutting,wood,decorative materials and other industries.
- Size: 8
- Place of Origin: China
- Brand Name: Huawei
- Model Number: 1212
- Weight: 700.000 kg
- :
- :
- :
- :
- :
- :
- :
- :
- :
- :
| Technical Date | |
| X Y working area | 1200mm*1200mm*120mm |
| table | Aluminum cast |
| Working precision | <0.04/300min |
| spindle power | 1.5kw optional: 2.2kw.3.0kw |
| spindle speed | 6000-24000rpm |
| tool diameter | Ø3.175mm Ø6mm Ø12.7mm |
| Interface | USB |
| command code | G code |
| working softward | NCSTUDIO system |
| working voltage | 220V/50HZ |
| dust power | 1.5kw |
| transmission | XY rack Zball screw |
| Motor | stepper motor |
| Certificate | CE |
